Product Details:
Payment & Shipping Terms:
|
| Model Numb: | Polyester(PET) Film Tape | Adhesive Side: | Single Sided |
|---|---|---|---|
| Rated Voltage: | As Customer Required | Industry: | Painting Or Electronics |
| Tensile Strength(Mpa): | >190 | Out Diamter(mm): | <650 |
| Thickness(mm）: | 0.012~0.15 | Elongation(%): | >100 |
| High Light: | waterproof electrical tape,insulated electrical tape |
||
Polyester tape(PET) is a kind of high voltage insulation material used widely in Cable industry for many years.
Polyester tape(PET) is used for forming the perfect shape on the cable. It provided high voltage and electrical isolation characteristics. And it has high temperature resistance to 260℃.
We can adjust the specification according the customers' demand.
| Material |
Thickness (mm) |
Width (mm) |
Length (m) |
ID (mm) |
OD (mm) |
| PET | 0.012~0.15 | 4~1250 | <8000 | 52mm±0.5mm 76mm±0.5mm 152mm±0.5mm |
<650 |
| AL+PET | 0.02~0.1 | 4~1250 | <8000 | ||
| AL+PET+EMAA | 0.05~0.1 | 6~1250 | <6000 | ||
| AL+PET+EVA | 0.03~0.1 | 4~1250 | <5000 | ||
| AL+PET+AL | 0.03~0.1 | 4~1250 | <8000 | ||
| AL+PET+AL+EMAA | 0.06~0.1 | 10~1250 | <5500 | ||
| Cu+PET | 0.035~0.1 | 4~1250 | <2000 | <300 | |
| Cu+PET+EMAA | 0.06~0.125 | 4~1250 | <2000 | ||
| Non-woven | 0.04~0.2 | 4~1000 | <8000 | ||
| Cotton Paper | 0.3~3 | 4~1000 | <8000 | ||
| Foamed PP | 0.05~0.3 | 4~1250 |
<8000 |
Product Parameter:
| Total Thickness | Weight | Yield | Tensile Strength | Elongation |
| (g/m2) | (m2/kg) | (Mpa) | (%) | |
| 12 mic | 16.8 | 59.5 | >190 | >100 |
| 15 mic | 21 | 47.6 | ||
| 19 mic | 26.6 | 37.6 | ||
| 23 mic | 32.2 | 31.1 | ||
| 36 mic | 50.4 | 19.8 | ||
| 50 mic | 70 | 14.3 | ||
| 75 mic | 105 | 9.5 | ||
| 100 mic | 140 | 7.1 | ||
| 125 mic | 175 | 5.7 |
1. Low-Cost.
2. Excellent tensile strength.
3. Good effects in insulation.
4. High voltage characteristic.
5. High temperature resistance and durability characteristic.
6. Wide application.
7. Pass the system of national and international quality certification.
Adhesive to Note:
1) glued should keep dry and clean, otherwise it will affect the adhesive tape stick and effect;
2) exert a certain force, make the combination of adhesive tape and glued thing well; After completion
3) when its use function, to peel tape as soon as possible, avoid the phenomenon of glue;
4) do not have UV resistant function of the adhesive tape, to avoid sun exposure, appearincomplete glue
phenomenon;
5) different environment and different don't stick, the same tape will show different results;
Such as glass. Is widely used in metal, plastic, etc., before the first trial.
Product Show:
